Belden 633938 rg6 plenum catv matv coax cable: superior performance the belden 633938 rg6 plenum catv matv duofoil al braid 1000ft coax cable is a high-performance solution for indoor surveillance cable tv catv and master antenna tv matv applications. This cmp and catvp-rated cable features a solid bare copper conductor foam fep core and belden s proprietary duofoil shielding combined with a 90% aluminum braid for exceptional signal integrity. The low-smoke pvc-ls jacket ensures compliance with plenum space requirements making it ideal for commercial and residential installations where fire safety is paramount. Product specifications:
Rg type: 6
Conductor: 18 awg solid bare copper 0.040 Inch nominal diameter
Insulation: foam fep fluorinated ethylene propylene 0.170-Inch nominal diameter white color
Outer shield: duofoil 100% coverage 90% aluminum braid
Outer jacket: low-smoke pvc 0.233 Inch nominal diameter
Overall cable diameter: 0.233 Inches 5.92 Mm
Impedance: 75 ohm
Velocity of propagation: 83%
Ul voltage rating: 300 v cmp
Temperature rating: -20 c to 75 c
Minimum bend radius: 2.3 Inches 58 mm
Maximum pull tension: 104 lbs 47.2 Kg
Weight: 28 lbs per 1000ft features and applications: ideal for catv and matv systems in commercial and residential buildings
Cmp and catvp rated for use in plenum spaces
High-performance duofoil aluminum braid shielding for superior signal quality
Low-smoke pvc-ls jacket for improved fire safety
Excellent attenuation char...
