Belden 633938 Rg6 Plenum Catv Matv Duofoil Braid 1000ft Coaxial Cable

Belden 633938 rg6 plenum catv matv coax cable: superior performance the belden 633938 rg6 plenum catv matv duofoil al braid 1000ft coax cable is a high-performance solution for indoor surveillance cable tv catv and master antenna tv matv applications. This cmp and catvp-rated cable features a solid bare copper conductor foam fep core and belden s proprietary duofoil shielding combined with a 90% aluminum braid for exceptional signal integrity. The low-smoke pvc-ls jacket ensures compliance with plenum space requirements making it ideal for commercial and residential installations where fire safety is paramount. Product specifications: Rg type: 6 Conductor: 18 awg solid bare copper 0.040 Inch nominal diameter Insulation: foam fep fluorinated ethylene propylene 0.170-Inch nominal diameter white color Outer shield: duofoil 100% coverage 90% aluminum braid Outer jacket: low-smoke pvc 0.233 Inch nominal diameter Overall cable diameter: 0.233 Inches 5.92 Mm Impedance: 75 ohm Velocity of propagation: 83% Ul voltage rating: 300 v cmp Temperature rating: -20 c to 75 c Minimum bend radius: 2.3 Inches 58 mm Maximum pull tension: 104 lbs 47.2 Kg Weight: 28 lbs per 1000ft features and applications: ideal for catv and matv systems in commercial and residential buildings Cmp and catvp rated for use in plenum spaces High-performance duofoil aluminum braid shielding for superior signal quality Low-smoke pvc-ls jacket for improved fire safety Excellent attenuation char... Brand: Belden Size: []
