Parameters voltage: 110v motor power: 1100w spindle speed: 7000r min material limit size: 5*5*5mm production capacity: 0.5-5Kg h 1.1Lbs-11lbs working noise: 85db direction of rotation: clockwise overall dimension: 560*380*820mm 22*14*32inch crushing fineness: 10 20 30 40 50 60 80 100 120 mesh notice 1. The universal pulverizer is only suitable for dry materials. Wet materials or liquid might make the machine break down. 2. Commercial grain grinder mill is not suitable for the too light material. 3.The screen is 80 mesh ship with original package. If you need other mesh size please contact us. 4.The output depend on the size of the mesh. The smaller particle will cause the lower output. Direction for use 1. Grinding machine should be checked before using the machine that whether transmission parts are loose or the other anomaly is produced the direction of the machine operation should be consistent with the direction of the arrow shown. 2. Taking no-load test for 1-2 minutes before using the machine. Materials can be feed after the machine is operating normally. Increasing the feed gradually and taking observation of electric current and the functioning of the motor. Blanking flashboard can be fixed only after feeding and current balance to be in normal. 3. Drying the materials or using coarse screen stencil if the materials are too wet or have poor mobility which cause poor discharge. Opening the front cover to replace the screen stencil. Hand wheel must be tightened to e...
