Ac110v-220v Digital Display Time Relay Automation Delay Timer Control Switch Relay Module

Specifications timing range 0 999s 0 999m 0 999hsupply voltage ac110v 220vrelay 20aworking current 10a max power 500w max size 79 26 43mmhole size 72 40mm instructions please pay attention for your first use you need wait 6s after your setting data the module will save the date you have set after 6s short press button set if you start the time setting mode nixie tube will blink you could adjust the time t1 and t2 by button and button please wait 5s after your setting date the module will save the date you have set after 5s long press button set if you start the parameter setting mode there are two group parameter for your choice p0 and p1 you could switch p0 or p1 by short press set under the parameter p0 and p1 you could set the timing mode by the button and button p0 0 timing time mode 0 999s p0 1 timing time mode 0 999min p0 2 timing time mode 0 999h p1 0 the relay will connect after you delay the t1 time p1 1 the relay will disconnect after you delay the t1 time p1 2 the relay will connect after you delay the t1 time first then the relay will disconnect after you delay the t2 time it finish p1 3 the relay will disconnect after you delay the t1 time first then the relay will connect after you delay the t2 time it finish p1 4 the relay will connect after you delay the t1 timefirst then the relay will disconnect after you delay the t2 time it is cyclic p1 5 the relay will disconnect after you delay the t1
